Drill Bits Ideal Step Drill Bit, 1/4 In. – 1 3/8 In.

Original price was: $100.00.Current price is: $70.00.

Detect co readings directly from your smartphone with the selection of this Ideal Step Drill Bit.

Quality You Can Count On

Prompt service, every time.

Quality Products, Quality Service

Effortless Shopping, Quality Products

IDEAL step drill bits for precise, repetitive drilling through the toughest materials including brass, carbon steel, cast iron, stainless steel, and more. These tough and reliable tools are constructed with a rugged titanium nitride exterior coating for protection, edge retention and corrosion resistance. Each step is gradually blended to ease stepping through hole sizes; reducing the need to keep changing drill bits. Split point design eliminates the need for a starter hole or punch and delivers three times faster starts, saving valuable time. The double-fluted design provides balanced cuts, more cutting surface compared to a single flute design, and cooler operation.

Titanium nitride coating dramatically extends bit life
Drills 10 different holes sizes 1/4 in. to 1 3/8 in., Step Increments 1/32 in., Step Thickness 1/16 in. – 1/4 in.
Split-point design for faster starts
Unique double-fluted design for balanced cuts and cooler operation
Shank 1 in. length
Max operating speed 1500 RPM
Do not use on hammer drills

Weight	6.25 lbs
Dimensions	2.75 × 1.40 × 1.40 in
Assembled Depth (in.)	1.75 in
Assembled Height (in.)	1.38 in
Assembled Width (in.)	1.38 in
Bit Diameter	1-3/8 in
Bit Length (in.)	2.75
Bit Material	Titanium
Drill Bit Type	Step
Drill Bit Type(s) Included	Step
Individual/Set	Individual
Material Application	Aluminum, Cast Iron, Duct/Sheet Metal, Stainless Steel, Steel
Model	35-517
Self-Feeding	Yes
Shank Diameter	3/8 in
Shank Style	3-Flat
